SHPF 150
Hydraulic Patch Fitting
(Non-Digging Floor Spring)
Specifications
Enquiry
• No digging or cutting of the floor is required
• Quick and easy installation
• Suitable door thickness: 10-15mm
• Speeds adjustable No.1 closing speed: 85°- 30°
• Speeds adjustable No.2 soft closing speed: 30°- 0°.
• Maximum opening 150° and controlled 135°
• 1.00 MM SS cover plate secured with pin system mechanism
• Unique base design, 5mm backward and forward, 7mm left and right, 5° alignment adjustment
• Suitable for Fire/Smoke Doors upto 40 min, Testing done by Intertek as per EN 1634-1:2008
• Ambient temperature: -20°C to +50°C
• Finish: Satin
