SHPF 100
Hydraulic Patch Fitting
(Non-Digging Floor Spring)
Specifications
Enquiry
• No digging or cutting of the floor is required
• Quick and easy installation
• For Interior Applications (Internal door)
• Suitable door thickness: 8-12mm
• Speeds adjustable No.1 closing speed: 85°- 30°
• Speeds adjustable No.2 soft closing speed: 30°- 0°.
• 1.00 MM SS cover plate secured with pin system mechanism
• CE Certified: Yes
• Opening angle of 140°double action, 90°hold-open
• Unique base design, 5mm backward and forward, 7mm left and right, 5° alignment adjustment
• Tested by Intertek as per EN 1154
• Finish : Satin
